EF3L15

Low Cost, Low Power

Product Brief

EF3L15 series FPGA products launched by Anlogic Infotech are positioned in the low-cost and low-power FPGA market. EF3L15 devices are intended for high-volume, cost-sensitive applications, enabling system designers to reduce costs while meeting growing bandwidth requirements. EF3L15 devices are based on the optimized low-power technology and deliver high functionality at the lowest cost.

Contact sales

Product Table

Find 3 Results

Device	DFFs	LUTs	DistributeRAM	eRAM-9K	eRAM-TotalBRAMBits	M18*18	PLL	USER IO	USER FLASH	Package Methods	Package Size
EF3L15CG256	1520	1520	12K	12	108K	8	1	207	4Mb	caBGA256	14*14
EF3L25CG256	2520	2520	20K	12	108K	8	1	207	4Mb	caBGA256	14*14
EF3L45CG256	4480	4480	35K	12	108K	15	1	207	4Mb	caBGA256	14*14

Product Features
Application Scenarios
Materials Download

Product Features

Flexible logical structure

1520-4800 LUTs, supporting up to 207 user IOs
Built-in flash

Built-in 4Mb flash, no external device required, supporting fast power-up
High-performance Flexible Input/Output Buffer

Compatible with 5V input and supporting hot-swapping
Enhanced security design

Each chip has a unique 64-bit DNA
