SALELF 2

Communication, Consumer electronics, Industrial display, IoT device

Product Brief

EF2 series FPGA products are the second generation of the "ELF" series launched by Anlogic Infotech, involving SoC FPGA products with embedded MCUs.

The products are based on 55 nm low-power technology and feature versatile configurations, high performance, and rich internal resources.

They are positioned in fields such as video capture, industrial control, and communications with far ranging adaptability.

Contact sales

Product Table

Find 13 Results

Device	DFFs	LUTs	DistributeRAM	eRAM-9K	eRAM-32K	eRAM-128k	eRAM-256k	eRAM-Total	M18*18	PLL	ADC	USER IO	Package Methods	Package Size
EF2S45VG81C	4480	4480	35k	12	6	1	1	684k	15	1		56	BGA81	4.2*4.2
EF2L15LG100B	1520	1520	12k	6	3	1	1	534k	8	1	2	80	LQFP100	14*14
EF2L15LG144B	1520	1520	12k	6	3	1	1	534k	8	1	2	113	LQFP144	20*20
EF2L45LG144B	4480	4480	35k	12	6	1	1	684k	15	1	2	113	LQFP144	20*20
EF2L45BG256B/H	4480	4480	35k	12	6	1	1	684k	15	1	2	206	FBGA256	17*17
EF2M45LG48B	4480	4480	35k	12	6	1	1	684k	15	1	2	35	LQFP48	9*9
EF2L45UG132	4480	4480	35k	12	6	1	1	684k	15	1	2	104	CSFBGA132	8*8
EF2M45LG144B	4480	4480	35k	12	6	1	1	684k	15	1	2	113	LQFP144	20*20
EF2M45VG81C	4480	4480	35k	12	6	1	1	684k	15	1	1	56	VFBGA81	4.2*4.2
EF2L25BG256B	2520	2520	20k	9	4	1	1	593k	12	1	2	206	FBGA256	17*17
EF2L25AG42P	2520	2520	20k	9	4	1	1	593k	12	1	\	29	XWFN42	4.2*4.2
EF2L25XG42B	2520	2520	20k	9	4	1	1	593k	12	1	2	29	XWFN42	4.2*4.2
EF2L15BG256B	1520	1520	12k	6	3	1	1	534k	8	1	2	206	FBGA256	17*17

Product Features
Application Scenarios
Materials Download

Product Features

Flexible logical structure

Logic scales from 1500 to 4480 LUTs
Built-in flash

Support fast power-up, no external device required
High performance IO

Support hot-swapping and MIPI HS/LP IO optimization
Enhanced security design

Each chip has a unique 64-bit DNA with AES encryption support for the bit stream
